BrightSign XT245
Standart Digital Signage Players
egenskaber
beskrivelse
yderligere information
lignende produkter
udskriv denne side
føj til notater
vis mine notater
PDF
egenskaber
beskrivelse
yderligere information
PDF
- PC-class HTML power with lightening quick, highly responsive 3D motion graphics powered by live data feeds
- Unique HDMI input integrates live video feeds from cameras and TV broadcasts into signage
- Vibrant HDR video from Full HD to brilliant 8K paired with crystal clear 4K graphics to display fine details and deep colors
- Dual 4K HDMI output option to streamline and simplify video wall and dual screen deployments
- PoE+ and an exhaustive I/O set built into a rugged ultra-thin design that operates reliably even in harsh conditions
- More power, flexibility, and purpose-built capabilities than other digital signage solutions
- Powered by BrightSignOS™ delivering legendary security, reliability, and uptimes
- Includes Control Cloud for real-time device monitoring and management anywhere, anytime
- Integrated with a huge global network of top CMS partners
BrightSign XT5 is built to elevate and future-proof your signage experiences with the perfect blend of power, performance, and versatility.
Industry-best video capabilities, immersive motion graphics and seamless live TV capabilities are the tools XT5 offers to create captivating displays for both single and dual screen experiences now and for years to come.
Specification
| XT245 | XT1145 | XT2145 | |
|---|---|---|---|
| I/O Package | Standard | Expanded | Multiplex |
| HTML5 Performance Level | 3D WebGL & real time data visualization | 3D motion graphics, video and live TV | Dual HTML presentations driving 2 screens |
| HDR10 Video Decoding | Single 8K60p Dual 4K60p (10-bit) Full HD |
Single 8K60p Dual 4K60p (10-bit) Full HD | Single 8K60p Dual 4K60p (10-bit) Full HD |
| Video Rotation | 4K & Full HD | 4K & Full HD | 4K & Full HD |
| Image & Graphics Decoding | 4K & Full HD | 4K & Full HD | 4K & Full HD |
| HDMI Outputs | 1x HDMI 2.1a | 1x HDMI 2.1a | 1x HDMI 2.1a 1x HDMI 2.0a |
| HDMI In* | HDMI 2.0a | HDMI 2.0a | |
| USB | 1x USB-A 1x USB-C | 1x USB-A 1x USB-C | |
| Serial | 3.5mm RS-232 | 3.5mm RS-232 | |
| GPIO | 12-pin Phoenix Connector with 8 bi-directional Ports | 12-pin Phoenix Connector with 8 bi-directional Ports | 12-pin Phoenix Connector with 8 bi-directional Ports |
| IR | 3.5mm In / Out | 3.5mm In / Out | 3.5mm In / Out |
| Ethernet | Gigabit with PoE+ | Gigabit with PoE+ | Gigabit with PoE+ |
| BrightSignOS | ✖ | ✖ | ✖ |
| Control Cloud Subscription | Included | Included | Included |
| BrightAuthor:connected Software | Included | Included | Included |
| Choice of Integrated CMS Solutions | ✖ | ✖ | ✖ |
| Optional BSN.cloud Subscription | ✖ | ✖ | ✖ |
| Optional WD-105 Wireless/Bluetooth Module | ✖ | ✖ | ✖ |
| Optional BrightSign Mobile USB Modem | ✖ | ✖ | |
| Optional 256GB SSD Storage | ✖ | ✖ | ✖ |
| Dimensions (WxDxH) | 238.62 x 185.9 x 19.19 mm | 238.62 x 185.9 x 19.19 mm | 238.62 x 185.9 x 19.19 mm |
| Warranty, parts and labor | 1 year (2 year in EU/UK) | 1 year (2 year in EU/UK) | 1 year (2 year in EU/UK) |
