Advantech BB-UE204

4-Port USB over Ethernet Server/Hub

Advantech BB-UE204
  • egenskaberegenskaber
  • beskrivelsebeskrivelse
  • yderligere informationyderligere information
  • PDFPDF
  • 10/100/1000 Mbps Ethernet
  • USB 2.0 @ 480 Mbps
  • Compact Size
  • 15 kV ESD Protection
  • International Power Supply Included
  • USB cable included

Model UE204, USB over IP Ethernet Server / Hub, allows multiple PCs to interact with USB peripheral devices over your local area network - a simple solution for accessing remote USB devices. High speed USB 2.0 (480 Mbps) and Gigabit Ethernet allows you to use high bandwidth devices such as IP cameras and some isochronous devices.

The free, easy-to-use software allows for simple installation and easy setup. Simply load the free software on your PC and it will locate the USB hub on the network and allow you to use peripheral devices as if they were attached locally. Ideal for applications in which a installing a local PC would be to cumbersome or expensive, such as kiosks or security applications.

ProdGrafik

SPECIFICATIONS

USB & ETHERNET TECHNOLOGY
USB Compatibility 1.1 and 2.0
USB Speed 1.5, 12, and 480 Mbps
USB Connector 4 x USB Type A Female
Ethernet 10/100/1000 Base T
Ethernet Connector RJ-45
IP Address Default = DHCP
169.254.10.10 if DHCP Not Available
User Configurable
Operating System Windows 7 (32/64 bit), Windows Vista (32/64 bit),
Windows XP (32/64 bit), Wondows 10 (32/64 bit)
Configuration Software Included with User Manual on CD
POWER
Source External PSU
Power Connector 5.5 mm Barrel Plug, Center Positive
Input Voltage 5 VDC
Power Consumption 2.5 A
USB Downstream Power 500 mA per Port
PSU Input 100 to 240 VAC, 50 / 60 Hz, 0.8 A
AC Input Blades US, EU, UK (included)
PSU Output 5 VDC, 3A
INDICATORS
Power / Active Green LED – ON when power applied
P1 – P4 Green LED – ON when USB port connected
MECHANICAL
Dimensions 10.0 x 6.0 x 28.9 cm (3.9 x 2.4 x 1.1 in)
Enclosure Plastic with panel mount slots on back
Weight UE204 – 95.3 g (0.21 lbs)
PSU – 72.4 g (0.38 lbs)
MEANTIME BEFORE FAILURE (MTBF)
MTBF UE204 63124 Hours
MTBF Calc. Method MIL 217F Parts Count Reliability
ENVIRONMENTAL
Operating Temperature 0 to 60 °C
Storage Temperature 0 to 70 °C
Operating Humidity 0 to 95% Non-condensing
APPROVALS / CERTIFICATIONS
Emissions FCC Class B, CISPR Class B (EN55022)
EN61000-4-2:2008 (ESD) +/-8kV Contact, +/-15kV Air
EN61000-4-3:2006 (RI) 10V/m, 80-1000MHz; 3V/m, 1.3 to 2.7 GHz
EN61000-4-4:2004 (EFT Burst) ±0.5V Power, ±1kV Data
EN61000-4-5:2005 (Surge) ±0.5kV DC, 2kV AC ±1kV Data
EN61000-4-6:2005 (CI) 10Vrms all ports
EN61000-4-8:2001 (Magnetic) 30 A/m




ORDERING INFORMATION

Available Modules
BB-UE204 4-Port USB over Ethernet Server/Hub (USB cable included)
