MOXA DA-660A Series

The DA-660A Series Arm-based, ready-to-run embedded computers are designed for industrial data-acquisition applications. The computers have 8 to 16 RS-232/422/485 serial ports, 4 Ethernet ports, and 2 USB 2.0 ports, all based on the MoxaMacro communication processor. In addition, the DA-662A-I-8/16-LX’s serial ports come with high-level interference protection. The housing is a standard 1U, 19-inch wide rack-mountable rugged enclosure. The robust, rack-mountable mechanism design provides the hardened protection needed for industrial environment applications, and makes it easy for users to install the DA-660A computers on a standard 19-inch rackmount.

The DA-660A computers are ideal for applications that require a distributed embedded technology, such as SCADA systems, plant-floor automation, and power electricity monitoring applications.

Specification

Computer


CPU
MoxaMacro 500 MHz

SDRAM
128 MB

Flash
NOR Flash, 32 MB

Pre-installed OS
Linux

LCD Module
Liquid Crystal Display on the case, 2x16 text mode



Ethernet Interface


Ethernet Ports
Auto-sensing 10/100 Mbps ports (RJ45 connector) x 4

Magnetic Isolation Protection
1.5 kV (built-in)



LED Indicators


System
System Ready x 1

Serial
2 per port (Tx, Rx)



Serial Interface


Serial Ports
8-port models: 8 x RS-232/422/485
16-port models: 16 x RS-232/422/485

Console Port
1 x RJ45



Serial Signal


Data Bits
5, 6, 7, 8

Stop Bits
1, 1.5, 2

Parity
None, Even, Odd, Space, Mark

Flow Control
RTS/CTS, XON/XOFF, ADDC® (automatic data direction control) for RS-485, RTS Toggle (RS-232 only)

Baudrate
50 bps to 921.6 kbps

RS-232
TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND

RS-422
Tx+, Tx-, Rx+, Rx-, GND

RS-485-4w
Tx+, Tx-, Rx+, Rx-, GND

RS-485-2w
Data+, Data-, GND



Power Parameters


Input Voltage
100 to 240 VAC

Power Consumption
20 W



Reliability


Alert Tools
Built-in buzzer and RTC (real-time clock)

Automatic Reboot Trigger
Built-in WDT



Physical Characteristics


Dimensions
480 x 45 x 237 mm (18.9 x 1.77 x 9.33 in)

Weight
4,300 g (9.56 lb)



Environmental Limits


Operating Temperature
-10 to 60°C (14 to 140°F)

Storage Temperature (package included)
-20 to 70°C (-4 to -158°F)

Ambient Relative Humidity
5 to 95% (non-condensing)

Vibration
1g @ IEC-68-2-6, sine wave (resonance search), 5-500 Hz, 1 Oct/min, 1 Cycle, 13 mins 17 sec per axis



Standards and Certification


Safety
UL 60950-1

EMC
EN 61000-6-2/-6-4

EMI
CISPR 22, FCC Part 15B Class A

EMS
IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 4 kV
IEC 61000-4-6 CS: 3 V/m
IEC 61000-4-8: 1 A/m
IEC 61000-4-11

Green Product
RoHS, CRoHS, WEEE



MTBF


Time
DA-662A-8-LX: 272,913 hrs
DA-662A-16-LX: 177,580 hrs
DA-662A-16-DP-LX: 177,260 hrs
DA-662A-I-8-LX: 268,332 hrs
DA-662A-I-16-LX: 189,455 hrs

Standards
Telcordia (Bellcore) Standard
