Gefen EXT-DVI-142DLN
1:2 Dual Link DVI Distribution Amplifier
egenskaber
beskrivelse
yderligere information
lignende produkter
udskriv denne side
føj til notater
vis mine notater
PDF
egenskaber
beskrivelse
yderligere information
PDF
- Split a Dual Link DVI signal to two DVI Dual Link outputs
- Allows simultaneous display of source on two screens
- Supports Single Link DVI resolutions up to 1920 x 1200, and dual-link up to 3840 x 2400
- Auto EQ compensates for any imperfections in the image
- Power On indicator
- DVI Link indicators
- Supports DDWG standard for DVI-compliant monitors
- HDCP pass-through on output #1
One Dual Link DVI Source Splitter to two Dual Link DVI Outputs
The Gefen EXT-DVI-142DLN Dual-link 1:2 DVI DL Distribution Amplifier splits video using a dual link DVI source such as a computer to two DVI dual link outputs such as monitors, without losing picture quality or the high resolution. Multiple1:2 DVI DL units can be cascaded from one to the next to create a flexible Dual Link DVI distribution system that can connect to multiple displays.
Video Support
Supports Single Link DVI resolutions up to 1920 x 1200, and dual-link up to 3840 x 2400
Specifications
- Maximum Pixel Clock:
2 x 165 MHz
Video Input Connector:
(1) DVI-D, 29-pin, female
Video Output Connectors:
(2) DVI-D, 29-pin, female
Power On indicator:
(1) LED, blue
Link indicators:
(2) LED, green
Power Consumption:
5 W (max.)
Power Supply:
5V DC
Operating Temperature:
+32 to +104 °F (0 to +40 °C)
Operating Humidity:
20% to 80% RH, non-condensing
Storage Temperature:
-4 to +140 °F (-20 to +60 °C)
Storage Humidity:
20% to 90% RH, non-condensing
MTBF:
50000 hours
Dimensions (W x H x D):
4" x 1.25" x 3.25" (102mm x 32mm x 83mm)
Shipping Weight:
2 lbs (0.9 kg)
