Bluefin 15.6" Finished Flex-OS Touch & PoE

Flex-OS Screens feature included HDMI connectivity, with no built in player required! If you do select a built in player, you can still plug in an external device and the screen will automatically change inputs. Upgrade, replace, or quickly swap between players without hanging a new screen!

Technical specifications

Display

• 15.6'' LCD Screen
• Resolution: 1920x1080
• Max Brightness: 300 nits
• Viewing Angle: 89/89/89/89
• Contrast: 700CR
• Optional: Capacitive Touch

System

• Included HDMI connectivity mini-USB touch screen override
• Optional Embedded Players:
  • BrightSign HS145
  • Bluefin Intel Ocean
  • Rockchip RK3399

Power

• Adapter Style: Micro Molex
• Adapter Output: 12V 2A
• Adapter SKU: 20-0150-0603
• Optional Power over Ethernet
• PoE 802.3at (30W)

Input / Output

• HDMI-In
• Mini-USB touch screen control
• 1x Micro-SD
• 1x USB 2.0
• Phoenix GPIO (4-pin Bi-Directional)
• 3.5mm RS232 Serial
• RJ45 Ethernet
• 3.5mm Analog/Digital Audio Out
• Optional Wi-Fi

Housing / Mounting

• Size: 14.8'' x 9.3'' x 1.7''
• Weight: 5.7 lbs (2.6kg)
• Mounting: VESA 100x100mm M4x6mm
